WYLEDK5 Ceiling Minor LED Surgical Lighting with Balance Arm

description1
Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Details

We are proudly introducing the WYLEDK surgical lighting system, which is a simpler LED lighting, while still delivering uncompromising light performance and cool, white high intensity light. It has been designed to illuminate operating room surgical fields and can be adjusted for light intensity in a variable pattern size. The result is the WYLEDK LED surgical light system: high performance optics in a familiar suspension.

Modern LED lighting technology
Traditional suspension
Variety of configurations: ceiling mounted, wall mounted and floor standing
A high-quality system to match your OR needs and your budget

The advanced LED technology in our lightheads offer:
High intensity
Cool, bright white light
Accurate color rendition
Superior deep-cavity illumination
Excellent shadow control
Energy efficiency

Technical Parameter

Technical Parameter

Model No.

WYLEDK5

Light intensity in Lux at 1 meter distance

50,000-150,000

Color Temperature (K)

4000±500

Color rendering index(Ra)

≥90

Focusable Light Field size (mm)

200±50

Working distance (mm)

60-140

Depth of Illuminance (mm)

≥800

Temperature increase in the head area

0.5℃

Radiance Energy (w/㎡)

600

Diameter of Lamp Head (mm)

500

Light Source LED (pcs)

25

Life-span of the LEDs

50, 000 h

Electric & frequency (V& Hz)

100-240 & 50/60

Packing List

Model No.

WYLEDK5

Light head

1

Supporting tube

1

Balance arm

1

Fixing plate

1

Hand grip

1

Service Manual

1

Installation tool

1

Spare safety wire

1
